MD310 Series

Compact Multi-functional Frequency Inverter

High Starting Speed, Comprehensive Braking, Multi-motor Switching Swing Frequency

The MD310 series frequency inverter is a general-purpose, compact, multi-functional inverter that employs open-loop vector and V/F control methods. It utilizes high-performance current vector control technology to achieve asynchronous motor control. The MD310 comes standard with an RS485 communication interface, supports Modbus RTU communication, and can be expanded with I/O expansion cards and CAN communication expansion cards. Built-in PID control facilitates the implementation of closed-loop process control systems, enabling up to 16 speed settings.

Three Phase 380-440V:
MD310T0.4B - 0.4kW
MD310T0.7B - 0.75kW
MD310T1.5B - 1.5kW
MD310T2.2B - 2.2kW
MD310T3.7B - 3.7kW
MD310T5.5B - 5.5kW
MD310T7.5B - 7.5kW
MD310T11B - 11kW
MD310T15B - 15kW
MD310T18.5B - 18.5kW
